Description
Bijur Delimon – Meter Unit FT-0: Medium Slow Flow, Tee Type
L. Dewitt's SKU #: B1112 | Mfr Part #: B1112The Bijur Delimon B1112 Meter Unit (Type FT-0) is a precision oil proportioning device for Single Line Resistance (SLR) cyclic lubrication systems. The FT is a tee-type unit with 1/8 NPT threads on both inlet and outlet, designed to tap into an existing pipe or tubing run and deliver "Medium Slow" metered oil to the bearing without interrupting the main line.
Regulated Medium Slow Flow
As a FT-0 model, this unit delivers Medium Slow flow — one of the most widely specified rates in standard machine tool lubrication. Suitable for a broad range of small-to-medium bearings where a light, consistent protective film is needed each cycle without excessive oil consumption or messy floor drip.
Cyclic System Integrity
An integrated 5 lb check valve ensures one-directional metered oil flow and prevents line drainage between pump cycles. For cyclic lubrication systems only. Not compatible with continuous-flow pumps.
Technical Specifications
| Type Designation | FT-0 (Tee Type) |
| Flow Rate | Medium Slow |
| Inlet Thread | 1/8 NPT |
| Outlet Thread | 1/8 NPT |
| Hex Size | 3/8" |
| Material | Brass |
Key Features
- 1/8 NPT on both inlet and outlet — all-American-standard thread
- Inline tee configuration taps into existing pipe run
- Integrated 5 lb check valve prevents back-drainage
- All-NPT equivalent of the FB (British Thread Tee Type)
Common Applications
- In-line lubrication taps on existing NPT pipe runs
- Multi-branch distribution networks
- Retrofit lubrication points on older NPT-piped machines
- Systems requiring an NPT tee connection at the bearing
Technical Support & System Design
Replacing an entire system or just a few points? L. Dewitt McCarter, Inc. is your authorized source for Bijur Delimon technical specifications and replacement parts.
Contact Our Technical TeamAdditional Information
Bijur Part Number: |
B1112 |
Thread Type: |
Inch thread - 5 lb check valve |
Type, Location & Mating Parts: |
Tee Type |
Flow Rate: |
Medium Slow |
