Bijur Delimon

Bijur Delimon ZVB02A303311 ZV-B Dual-Line Distributor, 2-Outlet, 3.0 cm³ per Outlet, Steel, Adjustable with Motion Indicator, with Weld-On Mounting Plate, 5,800 psi

(No reviews yet) Write a Review

Tracked & insured shipping

Free Returns



30 Days Money Back Guarantee

SKU:
ZVB02A303311
MPN:
ZVB02A303311
Condition:
New
Weight:
0.00 LBS
Shipping:
Calculated at Checkout
  • ZV-B 3.0CC 2 OUTLETS ADJ
  • ZV-B 3.0CC 2 Outlets ADJ
MSRP: $415.12
$377.75
— You save $37.37
Frequently bought together:

Description

Bijur Delimon ZV-B Dual-Line Distributor — ZVB02A303311

2-Outlet  ·  3.0 cm³ per Outlet  ·  Steel, Zinc-Nickel Plated  ·  Adjusting Device with Motion Indicator (1–2 outlets)

The Bijur Delimon ZV-B Dual-Line Distributor (ZVB02A303311) is a precision block-type metering distributor for dual-line centralized lubrication systems. Constructed from Steel, Zinc-Nickel Plated, this 2-outlet unit meters 3.0 cm³ of grease or oil per outlet per cycle. The distributor operates hydraulically — no springs — driven entirely by the pressure of the lubricant in the active main line. Each lubrication cycle consists of two strokes: when Main Line I is pressurized (Main Line II relieved), the associated outlets fire; then when Main Line II is pressurized, the alternating outlets fire. This ensures every bearing point is served every complete cycle.

Configuration Details

  • Part Number: ZVB02A303311
  • Outlets: 2
  • Metering Volume: 3.0 cm³ per outlet per cycle
  • Body Material: Steel, Zinc-Nickel Plated
  • Metering Device: Adjusting Device with Motion Indicator (1–2 outlets)
  • Accessories: Weld-On Mounting Plate (variant)
  • Main Line Connections: G 3/8 (4 total — 2 per face, optional)
  • Outlet Connections: G 1/4 (2 total)
  • Approx. Body Length: 68 mm

Technical Specifications

Max Operating Pressure 5,800 psi (400 bar)
Min Actuating Pressure 145 psi (10 bar)
Metering Volume 3.0 cm³ per outlet per cycle
Actuating Volume 0.3 cm³ per cycle
Temperature Range -20°C to +120°C (-4°F to +248°F)
Lubricant (Grease) Up to NLGI Class 3 (DIN 51818)
Lubricant (Oil) ISO VG 68–1500; service viscosity ≥190 mm²/s
Body Material Steel, Zinc-Nickel Plated
Seals Viton (FKM) — heat and synthetic lubricant resistant

Key Features

  • Springless hydraulic operation — driven entirely by lubricant pressure
  • Metering is independent of back pressure at each lubrication point
  • Adjusting device with motion indicator — visual confirmation of piston cycling
  • Includes SMS-standard weld-on mounting plate with fixing screws for direct equipment mounting
  • Steel, Zinc-Nickel Plated body — 1,000-hour salt spray rated zinc-nickel plating
  • Viton seals standard — compatible with synthetic lubricants and high heat
  • G 3/8 dual main-line connections on both faces — flexible installation orientation
  • Expandable system — up to 20 distributors can be combined in one dual-line circuit
  • Cross-porting available via internal set screw and plug

Typical Applications

  • Machine tools — spindles, guideways, gearboxes, and rotary tables
  • Steel mills and heavy rolling equipment with high back pressure
  • Paper machines, printing presses, and textile machinery
  • Construction and mining equipment (mobile applications)
  • Industrial presses and stamping equipment
  • Any dual-line system requiring precise, independent volumetric metering
How It Works & Service Notes

Each outlet's metering device allows continuous adjustment from the minimum (approx. 25% of max) to the full 3.0 cm³ dose, without disassembly. The motion indicator provides at-a-glance visual confirmation that the distributor is cycling. The distributor has one metering piston and one control piston for every two lubrication points — each full operating cycle consists of two strokes (one per main line). To cross-port two opposing outlets, remove set screw (item 6) and screw plug (item 7). Service seal kits are available: ZVBETA0005 (0.5 & 1.5 cm³ units) or ZVBETA0006 (3.0 cm³ units). Refer to Bijur Delimon document P_2018_1_GB_ZVB for complete installation and service procedures.

View AllClose

Warranty Information

This product comes with a 30 day money back guarantee.
View AllClose

Additional Information

Bijur Part Number:
ZVB02A303311
Series:
ZV-B Dual-Line Distributor
Body Material:
Steel (Zinc-Nickel Plated)
Outlets:
2
Metering Volume:
3.0 cm³ per outlet per cycle
Metering Device:
Adjusting Device with Motion Indicator (1–2 outlets)
Accessories:
Weld-On Mounting Plate (variant)
Max Operating Pressure:
5,800 psi (400 bar)
