Description
Bijur Delimon ZV-B Dual-Line Distributor — ZVB06A153522
6-Outlet · 1.5 cm³ per Outlet · Steel, Zinc-Nickel Plated · Adjusting Device with Motion Indicator (5–6 outlets)
The Bijur Delimon ZV-B Dual-Line Distributor (ZVB06A153522) is a precision block-type metering distributor for dual-line centralized lubrication systems. Constructed from Steel, Zinc-Nickel Plated, this 6-outlet unit meters 1.5 cm³ of grease or oil per outlet per cycle. The distributor operates hydraulically — no springs — driven entirely by the pressure of the lubricant in the active main line. Each lubrication cycle consists of two strokes: when Main Line I is pressurized (Main Line II relieved), the associated outlets fire; then when Main Line II is pressurized, the alternating outlets fire. This ensures every bearing point is served every complete cycle.
Configuration Details
- Part Number: ZVB06A153522
- Outlets: 6
- Metering Volume: 1.5 cm³ per outlet per cycle
- Body Material: Steel, Zinc-Nickel Plated
- Metering Device: Adjusting Device with Motion Indicator (5–6 outlets)
- Accessories: Weld-On Mounting Plate (5–6 outlets)
- Main Line Connections: G 3/8 (4 total — 2 per face, optional)
- Outlet Connections: G 1/4 (6 total)
- Approx. Body Length: 118 mm
Technical Specifications
| Max Operating Pressure | 5,800 psi (400 bar) |
| Min Actuating Pressure | 145 psi (10 bar) |
| Metering Volume | 1.5 cm³ per outlet per cycle |
| Actuating Volume | 0.3 cm³ per cycle |
| Temperature Range | -20°C to +120°C (-4°F to +248°F) |
| Lubricant (Grease) | Up to NLGI Class 3 (DIN 51818) |
| Lubricant (Oil) | ISO VG 68–1500; service viscosity ≥190 mm²/s |
| Body Material | Steel, Zinc-Nickel Plated |
| Seals | Viton (FKM) — heat and synthetic lubricant resistant |
Key Features
- Springless hydraulic operation — driven entirely by lubricant pressure
- Metering is independent of back pressure at each lubrication point
- Adjusting device with motion indicator — visual confirmation of piston cycling
- Includes SMS-standard weld-on mounting plate with fixing screws for direct equipment mounting
- Steel, Zinc-Nickel Plated body — 1,000-hour salt spray rated zinc-nickel plating
- Viton seals standard — compatible with synthetic lubricants and high heat
- G 3/8 dual main-line connections on both faces — flexible installation orientation
- Expandable system — up to 20 distributors can be combined in one dual-line circuit
- Cross-porting available via internal set screw and plug
Typical Applications
- Machine tools — spindles, guideways, gearboxes, and rotary tables
- Steel mills and heavy rolling equipment with high back pressure
- Paper machines, printing presses, and textile machinery
- Construction and mining equipment (mobile applications)
- Industrial presses and stamping equipment
- Any dual-line system requiring precise, independent volumetric metering
Each outlet's metering device allows continuous adjustment from the minimum (approx. 25% of max) to the full 1.5 cm³ dose, without disassembly. The motion indicator provides at-a-glance visual confirmation that the distributor is cycling. The distributor has one metering piston and one control piston for every two lubrication points — each full operating cycle consists of two strokes (one per main line). To cross-port two opposing outlets, remove set screw (item 6) and screw plug (item 7). Service seal kits are available: ZVBETA0005 (0.5 & 1.5 cm³ units) or ZVBETA0006 (3.0 cm³ units). Refer to Bijur Delimon document P_2018_1_GB_ZVB for complete installation and service procedures.
Additional Information
Bijur Part Number: |
ZVB06A153522 |
Series: |
ZV-B Dual-Line Distributor |
Body Material: |
Steel (Zinc-Nickel Plated) |
Outlets: |
6 |
Metering Volume: |
1.5 cm³ per outlet per cycle |
Metering Device: |
Adjusting Device with Motion Indicator (5–6 outlets) |
Accessories: |
Weld-On Mounting Plate (5–6 outlets) |
