Description
Insize 6539-100 – Magnetic Square with V Groove, 4x4x4IN
L. Dewitt's SKU #: 6539-100 | Mfr Part #: 6539-100Insize 6539-100 is a 4x4x4IN magnetic square with V grooves that holds flat and cylindrical work for inspection and marking. Magnetic force is on the top, left, right and V grooves.
Key Features
- Size 4x4x4IN
- Holds flat and cylindrical workpieces
- Magnetic force on top, left, right and V grooves
- Parallelism and squareness of top, bottom, left, right and back: 394μin
- Parallelism and squareness of V groove to the faces: 394μin
Technical Specifications
| Part Number | 6539-100 |
| Brand | Insize |
| Manufacturer Part Number | 6539-100 |
| Product Type | Magnetic Square with V Groove |
| Size | 4x4x4IN |
| Parallelism / Squareness | 394μin |
| Magnetic Faces | Top, left, right, V grooves |
| Availability | Ships direct from Insize; most items in stock. Ship date confirmed by email after you order. |
| Shipping Weight | 15.43 lb |
| Package Dimensions | 7.87IN L x 7.87IN W x 7.87IN H |
| UPC/EAN | 6940561952650 |
| Sold As | 1 Each |
Choosing between options
- Non-magnetic, hardened alternative: 6547-E1 right angle plate with V groove (236μin).
Request a Quote
Need volume pricing or help matching the right Insize part?
Send the part number, quantity and part size and shape — we reply the same day.
Contact Information
Authorized Insize distributor
📍 Nationwide shipping | Live Oak, TX
Additional Information
Brand: |
Insize |
Manufacturer Part Number: |
6539-100 |
Product Family: |
Testing and Specialty Instruments |
Supplier Category Code: |
A |
EAN: |
6940561952650 |
Package Weight: |
15.43 lb |
Package Length: |
7.87 in |
Package Width: |
7.87 in |
Package Height: |
7.87 in |
Feature 1: |
Hold flat and cylindrical workpieces for inspection and marking. |
Feature 2: |
Magnetic force on top, left, right and V grooves. |
Feature 3: |
Parallelism and squareness of top, bottom, left, right and back: 394μin. |
Feature 4: |
Parallelism and squareness of V groove to top, bottom, left, right and back: 394μin. |
