Insize 3533-50BE – Digital Spline Micrometer, Type B, 1-2IN/25-50MM
L. Dewitt's SKU #: 3533-50BE | Mfr Part #: 3533-50BEInsize 3533-50BE is a 1-2IN/25-50MM digital spline micrometer, type B, reading to .00005IN/0.001MM, for measuring splined shafts, slots and keyways. IP65 sealed, with data output for SPC.
Key Features
- Range 1-2IN/25-50MM, resolution .00005IN/0.001MM
- Measures splined shafts, slots and keyways
- IP65 dust- and water-resistant
- Buttons: on/off, set, inch/mm, ABS/INC
- Data output (cable sold separately)
- LR44 battery with auto power off
- Ratchet stop for consistent measuring force
- Carbide measuring faces
- Setting standard included
Technical Specifications
| Part Number | 3533-50BE |
| Brand | Insize |
| Manufacturer Part Number | 3533-50BE |
| Product Type | Digital Spline Micrometer, Type B |
| Range | 1-2IN/25-50MM |
| Resolution | .00005IN / 0.001MM |
| Protection Rating | IP65 |
| Data Output | Yes (cable sold separately) |
| Battery | LR44 |
| Measuring Faces | Carbide |
| Setting Standard | Included |
| Availability | Ships direct from Insize; most items in stock. Ship date confirmed by email after you order. |
| Shipping Weight | 1.91 lb |
| Package Dimensions | 10.04IN L x 5.83IN W x 1.69IN H |
| UPC/EAN | 6928640355851 |
| Sold As | 1 Each |
What you'll also need
- Data output cable (sold separately)
Choosing between options
- No electronics needed? 3233-2B is the mechanical 1-2IN spline micrometer (type B), graduation .0001IN.
Other sizes & versions in this series
Request a Quote
Need volume pricing or help matching the right Insize part?
Send the part number, quantity and the spline or keyway dimension and type (A or B) — we reply the same day.
Contact Information
Authorized Insize distributor
📍 Nationwide shipping | Live Oak, TX
Additional Information
Brand: |
Insize |
Manufacturer Part Number: |
3533-50BE |
Product Family: |
Micrometers |
Supplier Category Code: |
A |
EAN: |
6928640355851 |
Package Weight: |
1.91 lb |
Package Length: |
10.04 in |
Package Width: |
5.83 in |
Package Height: |
1.69 in |
Feature 1: |
Resolution .00005'/0.001mm. |
Feature 2: |
Measure splined shafts, slots and keyways. |
Feature 3: |
IP65 dust/waterproof. |
Feature 4: |
Button function: on/off, set, inch/mm, ABS/INC. |
Feature 5: |
Data output. LR44 battery, automatic power off. |
Feature 6: |
Ratchet stop. Carbide measuring faces. |
Feature 7: |
Supplied with setting standards (except 0-1'/0-25mm). |
Feature 8: |
Optional accessory: data output cable. |
