Description
Insize 3530-50BE – Digital Point Micrometer, Type B, 1-2IN/25-50MM
L. Dewitt's SKU #: 3530-50BE | Mfr Part #: 3530-50BEInsize 3530-50BE is a 1-2IN/25-50MM digital point micrometer, type B, reading to .00005IN/0.001MM. Pointed carbide tips reach the web thickness of drills, small grooves and keyways that flat measuring faces cannot.
Key Features
- Range 1-2IN/25-50MM, resolution .00005IN/0.001MM
- Measures drill web thickness, small grooves and keyways
- IP65 dust- and water-resistant
- Buttons: on/off, set, inch/mm, ABS/INC
- Data output (cable sold separately)
- LR44 battery with auto power off
- Ratchet stop for consistent measuring force
- Carbide tips
- Setting standard included
Technical Specifications
| Part Number | 3530-50BE |
| Brand | Insize |
| Manufacturer Part Number | 3530-50BE |
| Product Type | Digital Point Micrometer, Type B |
| Range | 1-2IN/25-50MM |
| Resolution | .00005IN / 0.001MM |
| Protection Rating | IP65 |
| Data Output | Yes (cable sold separately) |
| Battery | LR44 |
| Tips | Carbide |
| Setting Standard | Included |
| Availability | Ships direct from Insize; most items in stock. Ship date confirmed by email after you order. |
| Shipping Weight | 1.9 lb |
| Package Dimensions | 10.04IN L x 5.83IN W x 1.69IN H |
| UPC/EAN | 6928640355752 |
| Sold As | 1 Each |
What you'll also need
- Data output cable (sold separately)
Choosing between options
- No electronics needed? 3230-2 is a mechanical 1-2IN point micrometer (type A), graduation .0001IN.
Other sizes & versions in this series
Request a Quote
Need volume pricing or help matching the right Insize part?
Send the part number, quantity and the range and tip type (A or B) you need — we reply the same day.
Contact Information
Authorized Insize distributor
📍 Nationwide shipping | Live Oak, TX
Additional Information
Brand: |
Insize |
Manufacturer Part Number: |
3530-50BE |
Product Family: |
Micrometers |
Supplier Category Code: |
A |
EAN: |
6928640355752 |
Package Weight: |
1.9 lb |
Package Length: |
10.04 in |
Package Width: |
5.83 in |
Package Height: |
1.69 in |
Feature 1: |
Resolution .00005'/0.001mm. |
Feature 2: |
Measure the web thickness of drills, small grooves and keyways. |
Feature 3: |
IP65 dust/waterproof. Button function: on/off, set, inch/mm, ABS/INC. |
Feature 4: |
Data output. LR44 battery, automatic power off. |
Feature 5: |
Ratchet stop. Carbide tips. |
Feature 6: |
Supplied with setting standards (except 0-1'/0-25mm). |
Feature 7: |
Optional accessory: data output cable. |
