Description
Insize 3352-50A – High Precision Digital Blade Micrometer/Snap Gage, 25-50MM/1-2IN, .0002MM/.00001IN
L. Dewitt's SKU #: 3352-50A | Mfr Part #: 3352-50AInsize 3352-50A is a 25-50MM/1-2IN high precision digital blade micrometer/snap gage reading to .0002MM/.00001IN, for measuring groove diameters on shafts and keyways. It has a data interface for sending readings to a computer or SPC system.
Key Features
- Range 25-50MM/1-2IN, resolution .0002MM/.00001IN
- Blade spindle and anvil for groove diameters of shafts and keyways
- Data interface for sending readings
- Absolute encoder: reference data is kept after power off
- One turn of the sleeve feeds the spindle .2IN; using the sleeve does not affect accuracy
- Pressing the fork retracts the spindle .12IN
- Linear ball bearings rated for ten million uses
- Carbide spindle and anvil
Technical Specifications
| Part Number | 3352-50A |
| Brand | Insize |
| Manufacturer Part Number | 3352-50A |
| Product Type | High Precision Digital Blade Micrometer/Snap Gage |
| Range | 25-50MM/1-2IN |
| Resolution | .0002MM / .00001IN |
| Data Output | Data interface |
| Encoder | Absolute |
| Measuring Faces | Carbide blades |
| Availability | Ships direct from Insize; most items in stock. Ship date confirmed by email after you order. |
| Shipping Weight | 4.63 lb |
| Package Dimensions | 15.4IN L x 11.02IN W x 3.54IN H |
| UPC/EAN | 6940561982176 |
| Sold As | 1 Each |
Choosing between options
- Want readings sent without a cable? 3352-50AWL is the same 25-50MM/1-2IN blade model with built-in wireless.
- Standard resolution is enough? 3532-50E is a digital blade micrometer for 1-2IN/25-50MM with .00005IN/0.001MM resolution.
Other sizes & versions in this series
