Description
Insize 3350-50 – High Precision Digital Snap Gage, 1-2IN/25-50MM
L. Dewitt's SKU #: 3350-50 | Mfr Part #: 3350-50Insize 3350-50 is a 1-2IN/25-50MM high precision digital snap gage reading down to .00001IN/0.0002MM, for fast repeated OD checks on production parts. Press the fork to retract the spindle, load the part and read the size; the absolute encoder keeps its reference after power off.
Key Features
- Range 1-2IN/25-50MM
- Resolution .00001IN/0.0002MM, .00005IN/0.001MM and .0005IN/0.01MM
- Absolute encoder: reference data is kept after power off
- One turn of the sleeve feeds the spindle .2IN; using the sleeve does not affect accuracy
- Pressing the fork retracts the spindle .12IN
- Linear ball bearings rated for ten million uses
- Measuring force 7-10N
Technical Specifications
| Part Number | 3350-50 |
| Brand | Insize |
| Manufacturer Part Number | 3350-50 |
| Product Type | High Precision Digital Snap Gage |
| Range | 1-2IN/25-50MM |
| Resolution | .00001IN / 0.0002MM, .00005IN / 0.001MM, .0005IN / 0.01MM |
| Encoder | Absolute |
| Spindle Retraction | .12IN |
| Measuring Force | 7-10N |
| Availability | Ships direct from Insize; most items in stock. Ship date confirmed by email after you order. |
| Shipping Weight | 3.97 lb |
| Package Dimensions | 12.91IN L x 11.3IN W x 3.62IN H |
| UPC/EAN | 6940561960327 |
| Sold As | 1 Each |
Choosing between options
- Want readings sent without a cable? 3350-50WL is the same 1-2IN/25-50MM snap gage with built-in wireless.
Other sizes & versions in this series
Request a Quote
Need volume pricing or help matching the right Insize part?
Send the part number, quantity and the diameter you need to check and how you collect readings — we reply the same day.
Contact Information
Authorized Insize distributor
📍 Nationwide shipping | Live Oak, TX
Additional Information
Brand: |
Insize |
Manufacturer Part Number: |
3350-50 |
Product Family: |
Gages and Reference Tools |
Supplier Category Code: |
A |
EAN: |
6940561960327 |
Package Weight: |
3.97 lb |
Package Length: |
12.91 in |
Package Width: |
11.3 in |
Package Height: |
3.62 in |
Feature 1: |
Resolution .00001'/0.0002mm, .00005'/0.001mm, .0005'/0.01mm |
Feature 2: |
Absolute encoder, the original data remains after power off |
Feature 3: |
One turn of sleeve makes .2' spindle feed |
Feature 4: |
Measurement accuracy is not affected by the use of sleeve |
Feature 5: |
Press the fork, the spindle retracts .12' |
Feature 6: |
Linear ball bearings for ten million times use |
Feature 7: |
Measuring force 7-10N |
