Insize ISD-V300A – Vision Measuring System with Computer, 12×8×8IN
L. Dewitt's SKU #: ISD-V300A | Mfr Part #: ISD-V300AInsize ISD-V300A is a vision measuring system with a 12 x 8 x 8IN measuring range, 0.7X-4.5X zoom objective and adjustable LED surface and contour lighting, for non-contact measurement of part features on screen. The computer is included.
Build your kit – save 5%
Add a matching accessory to this tool in the same order and 5% comes off both automatically in your cart.
| Optional: ISD-V-PROBE probe, ISD-V-OB2X or ISD-V-OB05X auxiliary objective | Choose yours |
Send us this part number and what you measure — we match the accessories you need and quote the kit the same day.Match my kit
Kit savings need at least one tool and one accessory in the same order. Excludes QMS, LDM, TLP and UTM measuring machines.
Key Features
- Measuring range 12 x 8 x 8IN
- Resolution .00002IN on X/Y/Z
- X/Y accuracy ≤(98.4+10L)μin, L = measuring length in inches
- Zoom objective 0.7X-4.5X
- Adjustable LED surface and contour illumination
- Windows 7/8/10; computer included
Technical Specifications
| Part Number | ISD-V300A |
| Brand | Insize |
| Manufacturer Part Number | ISD-V300A |
| Product Type | Vision Measuring System with Computer |
| Measuring Range | 12 x 8 x 8IN |
| Resolution | .00002IN |
| X/Y Accuracy | ≤(98.4+10L)μin |
| Objective | 0.7X-4.5X zoom |
| Illumination | LED surface and contour, adjustable |
| Operating System | Windows 7/8/10 |
| Computer | Included |
| Availability | Ships direct from Insize; most items in stock. Ship date confirmed by email after you order. |
| Shipping Weight | 462.97 lb |
| Package Dimensions | 39.37IN L x 39.37IN W x 57.09IN H |
| UPC/EAN | 6928640384981 |
| Sold As | 1 Each |
What you'll also need
- Optional: ISD-V-PROBE probe, ISD-V-OB2X or ISD-V-OB05X auxiliary objective
Choosing between options
- Need CNC automation? ISD-V270CNCA-U is a CNC vision measuring system with the same 0.7X-4.5X zoom and X/Y accuracy formula.
Other sizes & versions in this series
Request a Quote
Need volume pricing or help matching the right Insize part?
Send the part number, quantity and part size and the features you need to measure (a drawing helps) — we reply the same day.
Contact Information
Authorized Insize distributor
📍 Nationwide shipping | Live Oak, TX
Additional Information
Brand: |
Insize |
Manufacturer Part Number: |
ISD-V300A |
Product Family: |
Optical and Video Inspection |
Supplier Category Code: |
B |
EAN: |
6928640384981 |
Package Weight: |
462.97 lb |
Package Length: |
39.37 in |
Package Width: |
39.37 in |
Package Height: |
57.09 in |
Feature 1: |
Resolution of X/Y/Z axis .00002' |
Feature 2: |
Accuracy of X/Y axis ≤(98.4+10L)μin (L is the measuring length in inch) |
Feature 3: |
Objective 0.7X ~ 4.5X (zoom) |
Feature 4: |
Illumination surface and contour with adjustable LED. |
Feature 5: |
Operation system Windows 7/8/10. |
