Description
Insize 4812-E – Thread Gage, Acme 29°, 1-10TPI
L. Dewitt's SKU #: 4812-E | Mfr Part #: 4812-EInsize 4812-E is an Acme 29° thread gage for 1-10 TPI, used to check and set screw-cutting tools.
Key Features
- Acme 29° thread form
- Pitches 1, 1-1/3, 1-1/2, 1-3/4, 2, 2-1/2, 3, 4, 5, 6, 7, 8, 9 and 10 TPI
- Angle accuracy ±10'
- Medium carbon steel
Technical Specifications
| Part Number | 4812-E |
| Brand | Insize |
| Manufacturer Part Number | 4812-E |
| Product Type | Thread Gage, Acme 29° |
| Thread Form | Acme 29° |
| Pitch Range | 1-10 TPI |
| Angle Accuracy | ±10' |
| Material | Medium carbon steel |
| Availability | Ships direct from Insize; most items in stock. Ship date confirmed by email after you order. |
| Shipping Weight | 0.12 lb |
| Package Dimensions | 4.33IN L x 3.86IN W x 0.12IN H |
| UPC/EAN | 6928640319334 |
| Sold As | 1 Each |
Choosing between options
- Metric trapezoidal 30° threads: 4812-12 covers 2-12MM pitches.
Other sizes & versions in this series
- 4812-12 – 2-12MM
Request a Quote
Need volume pricing or help matching the right Insize part?
Send the part number, quantity and thread form and pitch range — we reply the same day.
Contact Information
Authorized Insize distributor
📍 Nationwide shipping | Live Oak, TX
Additional Information
Brand: |
Insize |
Manufacturer Part Number: |
4812-E |
Product Family: |
Gages and Reference Tools |
Supplier Category Code: |
A |
EAN: |
6928640319334 |
Package Weight: |
0.12 lb |
Package Length: |
4.33 in |
Package Width: |
3.86 in |
Package Height: |
0.12 in |
Feature 1: |
To check and set screw cutting tools. |
Feature 2: |
Angle accuracy: ±10min.pe |
Feature 3: |
Acme 29 Degree |
Feature 4: |
1 - 10TPI, Pitch: 1, 1-1/3, 1-1/2, 1-3/4,2,2-1/2,3,4,5,6,7,8,9,10 TPI |
Feature 5: |
Made of medium carbon steel |
