Insize 4634-1C27 – NPT Thread Ring Gage, 1/8x27NPT
L. Dewitt's SKU #: 4634-1C27 | Mfr Part #: 4634-1C27Insize 4634-1C27 is an NPT thread ring gage for 1/8-27 NPT external pipe threads, made to ANSI/ASME B1.20.1. Use it to check tapered male pipe threads on fittings, nipples and threaded parts.
Key Features
- Thread size 1/8-27 NPT
- American tapered pipe thread (NPT), for threads sealed with sealant
- Made to ANSI/ASME B1.20.1
- Taper 1:16
- Oil hardened non-shrinking steel (OHNS)
Technical Specifications
| Part Number | 4634-1C27 |
| Brand | Insize |
| Manufacturer Part Number | 4634-1C27 |
| Product Type | NPT Thread Ring Gage |
| Thread Size | 1/8-27 NPT |
| Thread Form | NPT (American tapered pipe) |
| Standard | ANSI/ASME B1.20.1 |
| Taper | 1:16 |
| Material | OHNS (oil hardened non-shrinking steel) |
| Availability | Ships direct from Insize; most items in stock. Ship date confirmed by email after you order. |
| Shipping Weight | 0.06 lb |
| Package Dimensions | 1.57IN L x 1.57IN W x 0.59IN H |
| UPC/EAN | 6928640346958 |
| Sold As | 1 Each |
Choosing between options
- Checking the internal thread? 4644-1C27 is the NPT thread plug gage for the same 1/8-27 NPT size.
