Description
Insize 4120-22N – Metric Thread Ring Gage, No Go, M22x2.5
L. Dewitt's SKU #: 4120-22N | Mfr Part #: 4120-22NInsize 4120-22N is the NO GO ring gage for M22x2.5 external threads, class 6g to ISO 1502. It checks that the pitch diameter is not below the minimum limit: a good thread should not screw into it. Pair it with the matching GO ring gage.
Please note: This is the NO GO ring only. GO and NO GO gages are sold separately.
Key Features
- Thread size M22x2.5, tolerance class 6g
- Made to ISO 1502
- NO GO member only; GO gage sold separately
- Manufacturer inspection certificate included
Technical Specifications
| Part Number | 4120-22N |
| Brand | Insize |
| Manufacturer Part Number | 4120-22N |
| Product Type | Metric Thread Ring Gage, No Go |
| Thread Size | M22x2.5 |
| Tolerance Class | 6g |
| Gage Member | NO GO |
| Standard | ISO 1502 |
| Certificate | Manufacturer inspection certificate |
| Availability | Ships direct from Insize; most items in stock. Ship date confirmed by email after you order. |
| Shipping Weight | 0.57 lb |
| Package Dimensions | 3.07IN L x 2.87IN W x 1.1IN H |
| UPC/EAN | 6928640341830 |
| Sold As | 1 Each |
What you'll also need
- Matching GO ring gage 4120-22 (sold separately)
Choosing between options
Other sizes & versions in this series
Request a Quote
Need volume pricing or help matching the right Insize part?
Send the part number, quantity and thread size, pitch, class and GO / NO GO — we reply the same day.
Contact Information
Authorized Insize distributor
📍 Nationwide shipping | Live Oak, TX
Additional Information
Brand: |
Insize |
Manufacturer Part Number: |
4120-22N |
Product Family: |
Gages and Reference Tools |
Supplier Category Code: |
A |
EAN: |
6928640341830 |
Package Weight: |
0.57 lb |
Package Length: |
3.07 in |
Package Width: |
2.87 in |
Package Height: |
1.1 in |
Feature 1: |
Go and No-Go gages are supplied separately. |
Feature 2: |
Class 6g. |
Feature 3: |
Standard ISO1502. |
Feature 4: |
Supplied with manufacturer inspection certificate. |
