Insize 3581-50E – Digital Screw Thread Micrometer, 1-2IN/25-50MM
L. Dewitt's SKU #: 3581-50E | Mfr Part #: 3581-50EInsize 3581-50E is a 1-2IN/25-50MM digital screw thread micrometer reading to .00005IN/0.001MM, for measuring the pitch diameter of external screw threads. The non-rotating spindle keeps the measuring tips aligned in the thread; data output sends readings to SPC.
Key Features
- Range 1-2IN/25-50MM, resolution .00005IN/0.001MM
- Measures pitch diameter of screw threads
- Buttons: on/off, set, inch/mm, ABS/INC
- Data output (cable sold separately)
- LR44 battery with auto power off
- Non-rotating spindle
- Ratchet stop for consistent measuring force
- 60° setting standard included
Technical Specifications
| Part Number | 3581-50E |
| Brand | Insize |
| Manufacturer Part Number | 3581-50E |
| Product Type | Digital Screw Thread Micrometer |
| Range | 1-2IN/25-50MM |
| Resolution | .00005IN / 0.001MM |
| Data Output | Yes (cable sold separately) |
| Battery | LR44 |
| Spindle | Non-rotating |
| Setting Standard | 60° setting standard included |
| Availability | Ships direct from Insize; most items in stock. Ship date confirmed by email after you order. |
| Shipping Weight | 1.9 lb |
| Package Dimensions | 10.04IN L x 5.83IN W x 1.69IN H |
| UPC/EAN | 6928640356223 |
| Sold As | 1 Each |
What you'll also need
- Measuring tips, Insize 7381 (optional)
- 55° setting standards for 55° threads (optional)
- Data output cable (sold separately)
Choosing between options
Other sizes & versions in this series
Request a Quote
Need volume pricing or help matching the right Insize part?
Send the part number, quantity and thread size, pitch and thread angle (60° or 55°) — we reply the same day.
Contact Information
Authorized Insize distributor
📍 Nationwide shipping | Live Oak, TX
Additional Information
Brand: |
Insize |
Manufacturer Part Number: |
3581-50E |
Product Family: |
Micrometers |
Supplier Category Code: |
A |
EAN: |
6928640356223 |
Package Weight: |
1.9 lb |
Package Length: |
10.04 in |
Package Width: |
5.83 in |
Package Height: |
1.69 in |
Feature 1: |
Resolution .00005'/0.001mm. |
Feature 2: |
Measure pitch diameter of screw threads. |
Feature 3: |
Button function: on/off, set, inch/mm, ABS/INC. |
Feature 4: |
Data output. |
Feature 5: |
LR44 battery, automatic power off. |
Feature 6: |
Non-rotating spindle. Ratchet stop. |
Feature 7: |
Supplied with 60° setting standards (except 0-1'/0-25mm). |
Feature 8: |
Optional accessory: 55°setting standards, measuring tips (part no. 7381), data output cable. |
