Description
Insize 3351-175 – High Precision Digital Micrometer/Snap Gage, 150-175MM/6-7IN
L. Dewitt's SKU #: 3351-175 | Mfr Part #: 3351-175Insize 3351-175 is a 150-175MM/6-7IN high precision digital micrometer/snap gage with adjustable resolution down to .00001IN/0.0002MM, for repeated OD checks on larger shafts and parts. It has a data interface for sending readings to a computer or SPC system.
Key Features
- Range 150-175MM/6-7IN
- Adjustable resolution .00001IN/0.0002MM, .00005IN/0.001MM or .0005IN/0.01MM
- Data interface for sending readings
- Absolute encoder: reference data is kept after power off
- One turn of the sleeve feeds the spindle .2IN; using the sleeve does not affect accuracy
- Pressing the fork retracts the spindle .12IN
- Linear ball bearings rated for ten million uses
- Carbide spindle and anvil
- Measuring force 5-8N
Technical Specifications
| Part Number | 3351-175 |
| Brand | Insize |
| Manufacturer Part Number | 3351-175 |
| Product Type | High Precision Digital Micrometer/Snap Gage |
| Range | 150-175MM/6-7IN |
| Resolution | .00001IN / 0.0002MM, .00005IN / 0.001MM, .0005IN / 0.01MM |
| Data Output | Data interface |
| Encoder | Absolute |
| Spindle Retraction | .12IN |
| Measuring Faces | Carbide |
| Measuring Force | 5-8N |
| Availability | Ships direct from Insize; most items in stock. Ship date confirmed by email after you order. |
| Shipping Weight | 7.28 lb |
| Package Dimensions | 18.9IN L x 7.68IN W x 3.54IN H |
| UPC/EAN | 6940561966923 |
| Sold As | 1 Each |
Choosing between options
- Want readings sent without a cable? 3351-175WL is the same 150-175MM/6-7IN model with built-in wireless.
Other sizes & versions in this series
Request a Quote
Need volume pricing or help matching the right Insize part?
Send the part number, quantity and the diameter you need to check and how you collect readings — we reply the same day.
Contact Information
Authorized Insize distributor
📍 Nationwide shipping | Live Oak, TX
Additional Information
Brand: |
Insize |
Manufacturer Part Number: |
3351-175 |
Product Family: |
Micrometers |
Supplier Category Code: |
A |
EAN: |
6940561966923 |
Package Weight: |
7.28 lb |
Package Length: |
18.9 in |
Package Width: |
7.68 in |
Package Height: |
3.54 in |
Feature 1: |
Adjustable resolution: .00001'/0.0002mm, .00005'/0.001mm, .0005'/0.01mm |
Feature 2: |
Absolute encoder, the original data remains after power off |
Feature 3: |
One turn of sleeve makes .2' spindle feed |
Feature 4: |
Measurement accuracy is not affected by the use of sleeve |
Feature 5: |
Press the fork, the spindle retracts .12' |
Feature 6: |
Linear ball bearings for ten million times use |
Feature 7: |
Carbide spindle and anvil |
Feature 8: |
Measuring force 5-8N |
