Insize 2118-10E – Back Plunger Type Digital Indicator, Flat Back, .5IN/12.7MM
L. Dewitt's SKU #: 2118-10E | Mfr Part #: 2118-10EInsize 2118-10E is a back plunger digital indicator, .5IN/12.7MM range, reading to .0005IN/0.01MM. The spindle comes out the back, so it fits setups where a standard indicator stem would be in the way.
Build your kit – save 5%
Add a matching accessory to this tool in the same order and 5% comes off both automatically in your cart.
| Data output cable, e.g. 7302-40M keyboard-format cable for digital indicators | Data Output Cable (Keyboard Format) | Add to cart |
Send us this part number and what you measure — we match the accessories you need and quote the kit the same day.Match my kit
Kit savings need at least one tool and one accessory in the same order. Excludes QMS, LDM, TLP and UTM measuring machines.
Key Features
- Range .5IN/12.7MM, resolution .0005IN/0.01MM
- Back plunger design
- Meets ASME B89.1.10-2001
- Digital and analog reading; display rotates 320° and its direction can be changed
- Buttons: tolerance GO/NO GO display, data preset, measuring direction change, max./min./TIR, inch/metric, absolute/incremental
- Keeps preset and tolerance data in memory after restart
- CR2032 battery, auto power off; data output
Technical Specifications
| Part Number | 2118-10E |
| Brand | Insize |
| Manufacturer Part Number | 2118-10E |
| Product Type | Back Plunger Type Digital Indicator, Flat Back |
| Range | .5IN / 12.7MM |
| Resolution | .0005IN/0.01MM |
| Back | Flat back |
| Standard | ASME B89.1.10-2001 |
| Battery | CR2032 |
| Data Output | Yes (cable sold separately) |
| Availability | Ships direct from Insize; most items in stock. Ship date confirmed by email after you order. |
| Shipping Weight | 0.67 lb |
| Package Dimensions | 9.06IN L x 3.82IN W x 5.31IN H |
| UPC/EAN | 6928640381522 |
| Sold As | 1 Each |
What you'll also need
- Data output cable, e.g. 7302-40M keyboard-format cable for digital indicators (sold separately)
- Optional backs and contact points
Choosing between options
Other sizes & versions in this series
- 2118-101E – Resolution .00005IN/0.001MM
