Description
YG-1 TTF22503R YG Tap Chip Breaker Short Chamfer TiN HSS-PM Spiral Flute Tap 3/8-24 H3
L. Dewitt's SKU #: TTF22503R | Mfr Part #: TTF22503RLong chips can turn blind-hole tapping into a slow, risky operation. YG Tap Chip Breaker taps help shops solve long chips, bird nesting, chip packing, tapping torque, tool wear, overfeeding risk, broken taps, and inconsistent thread finish with chip-breaker flute geometry, a 15 degree helix, HSS-PM toughness, and TiN wear resistance.
- CNC machinists and programmers tapping blind holes in steels where long chips or bird nesting slow the job down.
- Production teams trying to reduce tap breakage, torque spikes, downtime, and inconsistent thread finish.
- Tool crib and purchasing teams matching taps by EDP, thread family, pitch limit, chamfer, coolant style, and thread size.
- Job shops and MRO buyers standardizing practical troubleshooting taps for non-alloy, alloy, high-alloy, and tool steels.
TTF22503R: YG-1 TTF22503R YG Tap Chip Breaker Short Chamfer TiN HSS-PM Spiral Flute Tap 3/8-24 H3 is a YG-1 HSS-PM spiral flute tap for blind-hole tapping where long chips, bird nesting, torque, and thread finish need to be controlled. Use this tap when chip control, blind-hole reliability, and thread finish matter more than simply cutting a thread.
Why This Model
Choose this model when the application calls for blind-hole tapping where long chips, bird nesting, torque, and thread finish need to be controlled. The chip breaker design is built to create shorter chips, improve chip evacuation, reduce friction, and support reliable thread finish in steel tapping jobs.
Technical Specifications
| Brand | YG-1 |
| Product Family | YG Tap Chip Breaker |
| Product Group | YG Tap Chip Breaker UNC / UNF Short Chamfer |
| Tool Type | HSS-PM spiral flute tap |
| Tool Style | TiN-coated chip breaker spiral flute tap short chamfer |
| Application | blind-hole tapping where long chips, bird nesting, torque, and thread finish need to be controlled |
| Coating | TiN |
| Substrate | HSS-PM |
| Manufacturer Part Number | TTF22503R |
| Measurement System | Inch |
| Package Unit | 1 |
| Series | TTF22 |
| Thread Family | UNC / UNF |
| Length Style | DIN Length / ANSI Shank |
| Thread Size | 3/8-24 |
| Threads Per Inch | 24 |
| Pitch Limit | H3 |
| Tool Material | HSS-PM |
| Flute Style | Spiral Flute |
| Helix Angle | 15 degrees |
| Thread Angle | 60 degrees |
| Chamfer Form | Form E |
| Chamfer Lead | 1.5P-2P |
| Coolant Style | Without Coolant |
| Hole Type | Blind Hole up to 2xD |
| Size | 3/8-24, H3 |
What This Solves
- Shorter, more manageable chips. Chip breaker flute geometry helps reduce bird nesting and chip packing in blind holes.
- Lower tapping risk. HSS-PM toughness and TiN coating support wear resistance, torque control, and reliable thread finish.
- Faster replacement matching. Thread size, pitch limit, chamfer style, coolant style, and series are grouped for clean purchasing decisions.
- More stable steel tapping. Built for non-alloy steel, low alloy steel, high alloy steel, and tool steel where conventional taps may struggle with chip control.
Common Applications
- Blind-hole tapping up to 2xD in CNC machining centers and production tapping operations
- Non-alloy steel, low alloy steel, high alloy steel, and tool steel applications
- Jobs with long chips, bird nesting, torque spikes, chip packing, thread finish problems, or tap-breakage risk
- Metric, UNC, and UNF replacement workflows where pitch limit, chamfer lead, and coolant style must be verified
Quick Answer
YG-1 TTF22503R YG Tap Chip Breaker Short Chamfer TiN HSS-PM Spiral Flute Tap 3/8-24 H3 is a YG-1 Tap Chip Breaker product used for blind-hole tapping where long chips, bird nesting, torque, and thread finish need to be controlled. It supports shorter chips, better evacuation, reduced torque load, longer tool life, and more reliable finished threads in steel applications.
- Product Family: YG Tap Chip Breaker
- Product Group: YG Tap Chip Breaker UNC / UNF Short Chamfer
- Tool Type: HSS-PM spiral flute tap
- Tool Style: TiN-coated chip breaker spiral flute tap short chamfer
- Coating: TiN
- Substrate: HSS-PM
- Manufacturer Part Number: TTF22503R
- Thread Family: UNC / UNF
- Thread Size: 3/8-24
- Threads Per Inch: 24
- Pitch Limit: H3
- Tool Material: HSS-PM
- Flute Style: Spiral Flute
- Helix Angle: 15 degrees
- Chamfer Form: Form E
- Chamfer Lead: 1.5P-2P
- Coolant Style: Without Coolant
- Hole Type: Blind Hole up to 2xD
- Availability: In Stock - Estimated Delivery in 3-5 Business Days
Common Questions
What is the YG-1 TTF22503R?
TTF22503R is a YG-1 HSS-PM spiral flute tap with chip breaker technology for blind-hole tapping in steel applications.
Why use a chip breaker tap?
Use a chip breaker tap when long chips, bird nesting, chip packing, torque, or thread finish are creating problems with conventional spiral flute taps.
What results should this product support?
When selected correctly, it supports shorter chips, cleaner evacuation, reduced tapping torque, less breakage risk, and more consistent finished threads.
How do I confirm the correct replacement?
Match EDP TTF22503R, thread size, pitch or TPI, pitch limit, chamfer lead, coolant style, tap drill size, work material, holder alignment, and tapping speed before ordering.
Image reference: YG-1 Tap Chip Breaker product TTF22503R.
Need Help Matching a Tap Chip Breaker?
Send us the EDP, thread size, pitch limit, coolant requirement, and work material. L. Dewitt McCarter, Inc. can help verify the correct YG-1 Tap Chip Breaker for your tapping application.
Contact Our Technical TeamAdditional Information
Manufacturer: |
YG-1 |
Manufacturer Part Number: |
TTF22503R |
Product Family: |
YG Tap Chip Breaker |
Product Group: |
YG Tap Chip Breaker UNC / UNF Short Chamfer |
Tool Category: |
YG Tap Chip Breaker |
Application Family: |
blind-hole tapping where long chips, bird nesting, torque, and thread finish need to be controlled |
Tool Type: |
HSS-PM spiral flute tap |
Tool Style: |
TiN-coated chip breaker spiral flute tap short chamfer |
Substrate: |
HSS-PM |
Package Unit: |
1 |
Size: |
3/8-24, H3 |
Measurement System: |
Inch |
Tool Material: |
HSS-PM |
Flute Style: |
Spiral Flute |
Helix Angle: |
15 degrees |
Thread Angle: |
60 degrees |
Hole Type: |
Blind Hole up to 2xD |
Series: |
TTF22 |
Thread Family: |
UNC / UNF |
Length Style: |
DIN Length / ANSI Shank |
Chamfer Form: |
Form E |
Chamfer Lead: |
1.5P-2P |
Coolant Style: |
Without Coolant |
Thread Limit Style: |
H |
Pitch Limit: |
H3 |
Thread Size: |
3/8-24 |
Threads Per Inch: |
24 |
