YG-1 D5322012 Carbide 120 Degree NC Spotting Drill 3/16 x 3/4 x 2
L. Dewitt's SKU #: D5322012 | Mfr Part #: D5322012Accurate holes begin before the drill is fully engaged. YG-1 NC spotting drills help shops solve drill walking, poor hole location, inconsistent starts, burr-prone chamfers, and wasted setup time before drilling by creating a controlled spot, chamfer, or starting feature that helps the next drill enter on location.
- CNC machinists and programmers setting up accurate drill starts, chamfer starts, and spot locations.
- Production teams trying to reduce drill walk, scrap risk, and rework from poor hole location.
- Tool crib and purchasing teams replacing NC spotting drill SKUs by EDP, diameter, point angle, substrate, and length.
- Job shops and MRO buyers standardizing spotting tools for steel, stainless, cast iron, aluminum, and mixed-material work.
D5322012: YG-1 D5322012 Carbide 120 Degree NC Spotting Drill 3/16 x 3/4 x 2 is a 120 Degree NC spotting drill used for spotting, chamfer-start preparation, and accurate drill-location work before production drilling. Use this model when the setup needs accurate location, controlled entry geometry, and a clear replacement path from quote to spindle.
Why This Model
Choose this NC spotting drill when the operation needs a reliable starting feature before drilling. The point angle, diameter, flute length, overall length, and substrate should be matched to the following drill, work material, holder rigidity, and programmed feed so the spot supports location accuracy without creating an oversized or brittle entry condition.
Technical Specifications
| Brand | YG-1 |
| Product Family | NC Spotting Drills |
| Product Group | Solid Carbide NC Spotting Drill 120 Degree |
| Tool Type | NC spotting drill |
| Tool Style | 120 Degree NC spotting drill |
| Point Angle | 120 Degree |
| Coating | Bright / Uncoated |
| Substrate | Carbide |
| Manufacturer Part Number | D5322012 |
| Measurement System | Inch |
| Package Unit | 1 |
| Cutting Diameter | 3/16 |
| Shank Diameter | 3/16 |
| Flute Length | 3/4 |
| Overall Length | 2 |
| Size | 3/16 x 3/4 x 2 |
What This Solves
- More accurate starts. Spotting creates a controlled entry point so the following drill is less likely to wander.
- Cleaner setup decisions. Angle, diameter, length, and substrate are organized for quick comparison before the job is loaded.
- Better drilling workflow. A matched spotting tool can reduce rework, location drift, and avoidable tool-change delays.
- Results after use. Shops should see more accurate hole starts, cleaner spot locations, better drill guidance, and improved setup confidence before the main drilling operation.
Common Applications
- Spotting, chamfer-start preparation, and accurate drill-location work before production drilling
- Non-alloy steel, low alloy steel, stainless steel, grey cast iron, nodular cast iron, malleable cast iron, aluminum, copper alloys, and selected non-metallic materials
- CNC machining centers, toolroom work, production drilling, maintenance machining, and repeat replacement programs
- Spotting before twist drills, carbide drills, short-hole drilling, chamfer starts, and precision hole-location workflows
Quick Answer
YG-1 D5322012 Carbide 120 Degree NC Spotting Drill 3/16 x 3/4 x 2 is a YG-1 NC spotting drill for accurate drill-start preparation, built to support cleaner starts, controlled location, and repeatable drilling setup work.
- Product Family: NC Spotting Drills
- Product Group: Solid Carbide NC Spotting Drill 120 Degree
- Tool Type: NC spotting drill
- Point Angle: 120 Degree
- Coating: Bright / Uncoated
- Substrate: Carbide
- Manufacturer Part Number: D5322012
- Measurement System: Inch
- Cutting Diameter: 3/16
- Shank Diameter: 3/16
- Flute Length: 3/4
- Overall Length: 2
Common Questions
What is the YG-1 D5322012?
D5322012 is a Carbide NC spotting drill used to create a controlled starting point before drilling.
When should I use an NC spotting drill?
Use it when the following drill needs help starting on location, especially in CNC setups where hole position, chamfer control, and repeatability matter.
What results should this product support?
When selected correctly, it supports cleaner drill entry, reduced walking, better hole-location confidence, and a smoother production drilling workflow.
How do I confirm the correct replacement?
Match EDP D5322012, diameter, point angle, flute length, overall length, substrate, holder setup, work material, and the following drill geometry before ordering.
