Description
Insize IST-1W30A – Digital Angle Torque Wrench, 53.1-265.5 in.lb/4.42-22.12 ft.lb
L. Dewitt's SKU #: IST-1W30A | Mfr Part #: IST-1W30AInsize IST-1W30A is a digital angle torque wrench reading 53.1-265.5 in.lb / 4.42-22.12 ft.lb with a 1/4IN square drive. It handles torque-plus-angle tightening: reach the set torque, then turn the set angle for the extra torque.
Build your kit – save 5%
Add a matching accessory to this tool in the same order and 5% comes off both automatically in your cart.
| Calibration cable IST-1W-CABLE | Calibration Cable | Add to cart |
| Digital torque tester | Insize torque testers to verify and reset the wrench. | Choose yours |
Send us this part number and what you measure — we match the accessories you need and quote the kit the same day.Match my kit
Kit savings need at least one tool and one accessory in the same order. Excludes QMS, LDM, TLP and UTM measuring machines.
Key Features
- Range 53.1-265.5 in.lb / 4.42-22.12 ft.lb; resolution 0.1 in.lb / 0.01 ft.lb, angle 1°
- Accuracy clockwise ±2%, counter-clockwise ±3%; angle ±2° (at 90° rotation)
- 1/4IN square drive
- Clockwise and counter-clockwise operation
- Units: in.lb, ft.lb, N·m, kg.cm, degree
- Peak and track modes
- Target torque or angle with audible and visible alarm
- Overload record when torque reaches 110% of max range
- Non-slip grip; auto power off after 5 minutes
Technical Specifications
| Part Number | IST-1W30A |
| Brand | Insize |
| Manufacturer Part Number | IST-1W30A |
| Product Type | Digital Angle Torque Wrench |
| Torque Range | 53.1-265.5 in.lb / 4.42-22.12 ft.lb |
| Resolution | 0.1 in.lb / 0.01 ft.lb; angle 1° |
| Accuracy | CW ±2%, CCW ±3%, angle ±2° |
| Square Drive | 1/4IN |
| Modes | Peak, track |
| Availability | Ships direct from Insize; most items in stock. Ship date confirmed by email after you order. |
| Shipping Weight | 2.89 lb |
| Package Dimensions | 18.7IN L x 4.72IN W x 2.56IN H |
| UPC/EAN | 6928640326318 |
| Sold As | 1 Each |
What you'll also need
- Calibration cable IST-1W-CABLE
Choosing between options
Other sizes & versions in this series
- IST-1W135A – 239-1195 in.lb/19.9-99.5 ft.lb
- IST-1W200A – 354-1770 in.lb/29.5-147.5 ft.lb
- IST-1W340A – 602- 3009 in.lb/50.1-250.7 ft.lb
Request a Quote
Need volume pricing or help matching the right Insize part?
Send the part number, quantity and torque range, drive size and whether you tighten by angle — we reply the same day.
Contact Information
Authorized Insize distributor
📍 Nationwide shipping | Live Oak, TX
Additional Information
Brand: |
Insize |
Manufacturer Part Number: |
IST-1W30A |
Product Family: |
Testing and Specialty Instruments |
Supplier Category Code: |
B |
EAN: |
6928640326318 |
Package Weight: |
2.89 lb |
Package Length: |
18.7 in |
Package Width: |
4.72 in |
Package Height: |
2.56 in |
Feature 1: |
Accuracy: clockwise ±2%, counter-clockwise ±3%, angle ±2° (rotate 90°). |
Feature 2: |
Res: torque 0.1in.lb/0.01ft.lb, angle 1°. Square driver 1/4'. |
Feature 3: |
Clockwise and counter-clockwise operation. |
Feature 4: |
Set the desired torque first. After reaching the desired torque, set the angle and turn the wrench at this angle to apply extra torque |
Feature 5: |
Unit: in.lb, ft.lb, N.m, kg.cm, degree. Peak and track working mode. |
Feature 6: |
Target torque or angle value can be set, with audible and visible alarm |
Feature 7: |
Power off in 5 minutes automatically. Non-slip grip handle. With damp record. |
Feature 8: |
With overload record (once the torque reaches 110% of the maximum range) |
