Description
Insize ISM-PM20 – Portable Measuring Microscope, 20X
L. Dewitt's SKU #: ISM-PM20 | Mfr Part #: ISM-PM20Insize ISM-PM20 is a 20X pocket measuring microscope with a graduated eyepiece reading .002IN/0.05MM and a .35IN diameter view field. It sits on its base directly on the part for reading small feature sizes, with its own LED light.
Key Features
- Total magnification 20X: 10X eyepiece with graduation, 2X achromatic objective (NA 0.05)
- Graduation .002IN/0.05MM
- View field .35IN diameter; focus range 1.18IN
- Working distance .68IN
- LED illumination
- Base diameter 2.48IN
Technical Specifications
| Part Number | ISM-PM20 |
| Brand | Insize |
| Manufacturer Part Number | ISM-PM20 |
| Product Type | Portable Measuring Microscope, 20X |
| Total Magnification | 20X |
| Objective | 2X achromatic, NA 0.05 |
| Graduation | .002IN / 0.05MM |
| View Field | .35IN DIA |
| Working Distance | .68IN |
| Base Diameter | 2.48IN |
| Illumination | LED |
| Availability | Ships direct from Insize; most items in stock. Ship date confirmed by email after you order. |
| Shipping Weight | 3.85 lb |
| Package Dimensions | 12.99IN L x 11.42IN W x 3.94IN H |
| UPC/EAN | 6928640371066 |
| Sold As | 1 Each |
Choosing between options
- Finer reading: ISM-PM40 (40X, graduation .001IN/0.025MM, view field .18IN DIA).
Request a Quote
Need volume pricing or help matching the right Insize part?
Send the part number, quantity and the feature size you need to measure — we reply the same day.
Contact Information
Authorized Insize distributor
📍 Nationwide shipping | Live Oak, TX
Additional Information
Brand: |
Insize |
Manufacturer Part Number: |
ISM-PM20 |
Product Family: |
Optical and Video Inspection |
Supplier Category Code: |
B |
EAN: |
6928640371066 |
Package Weight: |
3.85 lb |
Package Length: |
12.99 in |
Package Width: |
11.42 in |
Package Height: |
3.94 in |
Feature 1: |
Total magnification 20X. Eyepiece 10X with graduation. |
Feature 2: |
Objective (achromatic) 2X (numerical aperture: 0.05). |
Feature 3: |
Working distance .68'. Graduation.002'/ 0.05mm. |
Feature 4: |
Viewing field .35'DIA. Focus range 1.18'DIA. |
Feature 5: |
Illumination LED light. Diameter of base 2.48'DIA |
