Description
Insize ISD-VMM235 – Toolmaker Microscope, Binocular, 11.81 x 7.87IN X/Y Travel
L. Dewitt's SKU #: ISD-VMM235 | Mfr Part #: ISD-VMM235Insize ISD-VMM235 is a binocular toolmaker microscope with 11.81 x 7.87IN X/Y travel and 7.87IN Z travel, magnifying 10X-100X, for measuring small part features, profiles and distances.
Key Features
- X/Y travel 11.81 x 7.87IN; Z travel 7.87IN
- Metal stage 19.69 x 12.99IN; glass stage 13.78 x 9.84IN
- Resolution .00002IN on X/Y/Z
- Repeatability .00008IN
- Optical magnification 10X-100X
- Binocular viewing
- Windows 7/8/10
Technical Specifications
| Part Number | ISD-VMM235 |
| Brand | Insize |
| Manufacturer Part Number | ISD-VMM235 |
| Product Type | Toolmaker Microscope, Binocular, 11.81 x 7.87IN X/Y Travel |
| X/Y Travel | 11.81 x 7.87IN |
| Z Travel | 7.87IN |
| Metal Stage Size | 19.69 x 12.99IN |
| Glass Stage Size | 13.78 x 9.84IN |
| Resolution | .00002IN |
| Repeatability | .00008IN |
| Magnification | 10X-100X |
| Viewing Head | Binocular |
| Operating System | Windows 7/8/10 |
| Availability | Ships direct from Insize; most items in stock. Ship date confirmed by email after you order. |
| Shipping Weight | 396.83 lb |
| Package Dimensions | 39.37IN L x 31.5IN W x 51.18IN H |
| UPC/EAN | 6940561940404 |
| Sold As | 1 Each |
Choosing between options
- Same 11.81 x 7.87IN travel with a monocular head: ISD-VMM235D.
Other sizes & versions in this series
- ISD-VMM205 – X/Y axis travel 5.91×3.94IN; Z axis travel 5.91IN
- ISD-VMM205D – Monocular
- ISD-VMM215 – X/Y axis travel 7.87×3.94IN; Z axis travel 5.91IN
- ISD-VMM215D – Monocular
- ISD-VMM225 – X/Y axis travel 9.84×5.91IN; Metal stage size 17.72×11.02IN
- ISD-VMM225D – Monocular
- ISD-VMM235D – Monocular
Request a Quote
Need volume pricing or help matching the right Insize part?
Send the part number, quantity and part size and the features you need to measure — we reply the same day.
Contact Information
Authorized Insize distributor
📍 Nationwide shipping | Live Oak, TX
Additional Information
Brand: |
Insize |
Manufacturer Part Number: |
ISD-VMM235 |
Product Family: |
Optical and Video Inspection |
Supplier Category Code: |
B |
EAN: |
6940561940404 |
Package Weight: |
396.83 lb |
Package Length: |
39.37 in |
Package Width: |
31.5 in |
Package Height: |
51.18 in |
Feature 1: |
X/Y axis travel 11.81×7.87” |
Feature 2: |
Z axis travel 7.87' |
Feature 3: |
Metal stage size 19.69×12.99' |
Feature 4: |
Glass stage size 13.78×9.84' |
Feature 5: |
Resolution of X/Y/Z axis .00002' |
Feature 6: |
Repeatability .00008' |
Feature 7: |
Optical magnification 10X~100X |
Feature 8: |
Operating system Window 7/8/10 |
