Description
Insize 7382-25 – 3-Wires, .0114IN/0.290MM
L. Dewitt's SKU #: 7382-25 | Mfr Part #: 7382-25Insize 7382-25 is a set of three .0114IN/0.290MM thread measuring wires for checking the pitch diameter of external threads with a standard outside micrometer that has a .256IN diameter spindle.
Key Features
- Wire diameter .0114IN/0.290MM
- Diameter accuracy ±20μin; cylindricity 39μin (1µm)
- Hardness HRC60
- For standard outside micrometers with a .256IN diameter spindle
- Manufacturer inspection certificate included
Technical Specifications
| Part Number | 7382-25 |
| Brand | Insize |
| Manufacturer Part Number | 7382-25 |
| Product Type | 3-Wires |
| Wire Diameter | .0114IN / 0.290MM |
| Diameter Accuracy | ±20μin |
| Cylindricity | 39μin (1µm) |
| Hardness | HRC60 |
| Micrometer Spindle | .256IN DIA |
| Certificate | Manufacturer inspection certificate |
| Availability | Ships direct from Insize; most items in stock. Ship date confirmed by email after you order. |
| Shipping Weight | 0.03 lb |
| Package Dimensions | 1.65IN L x 1.57IN W x 0.59IN H |
| UPC/EAN | 6928640361937 |
| Sold As | 1 Set (3 wires) |
What you'll also need
- Outside micrometer with .256IN diameter spindle
Choosing between options
Other sizes & versions in this series
Request a Quote
Need volume pricing or help matching the right Insize part?
Send the part number, quantity and thread pitch (TPI) and thread form — we reply the same day.
Contact Information
Authorized Insize distributor
📍 Nationwide shipping | Live Oak, TX
Additional Information
Brand: |
Insize |
Manufacturer Part Number: |
7382-25 |
Product Family: |
Micrometers |
Supplier Category Code: |
A |
EAN: |
6928640361937 |
Package Weight: |
0.03 lb |
Package Length: |
1.65 in |
Package Width: |
1.57 in |
Package Height: |
0.59 in |
Feature 1: |
Used with standard outside micrometers with spindle .256'DIA to measure pitch diameter of screw threads. |
Feature 2: |
Diameter accuracy: ±20μin. Cylindricity: 39μin. |
Feature 3: |
Cylindricity: 1um. Hardness: HRC60. |
Feature 4: |
Supplied with manufacturer inspection certificate. |
Feature 5: |
Supplied with manufacturer inspection certificate. |
