Insize 6528-85 – Precision Universal Vise with Chuck
L. Dewitt's SKU #: 6528-85 | Mfr Part #: 6528-85Insize 6528-85 is a precision universal vise with a chuck for round parts; it rotates 360° horizontally and tilts 45° vertically, both graduated in 0.05°. Chuck runout is under .0003IN when tested within 1.97IN of the jaws.
Build your kit – save 5%
Add a matching accessory to this tool in the same order and 5% comes off both automatically in your cart.
Send us this part number and what you measure — we match the accessories you need and quote the kit the same day.Match my kit
Kit savings need at least one tool and one accessory in the same order. Excludes QMS, LDM, TLP and UTM measuring machines.
Key Features
- Horizontal rotation 360°, graduation 0.05°
- Vertical incline 45°, graduation 0.05°, with incline adjust knob
- Chuck runout under .0003IN (test position less than 1.97IN from the clamping jaws)
- Reversible chuck jaws
- Tool steel, hardness HRC56-58
Technical Specifications
| Part Number | 6528-85 |
| Brand | Insize |
| Manufacturer Part Number | 6528-85 |
| Product Type | Precision Universal Vise with Chuck |
| Horizontal Rotation | 360°, 0.05° graduation |
| Vertical Incline | 45°, 0.05° graduation |
| Chuck Runout | <.0003IN |
| Material | Tool steel |
| Hardness | HRC56-58 |
| Availability | Ships direct from Insize; most items in stock. Ship date confirmed by email after you order. |
| Shipping Weight | 24.25 lb |
| Package Dimensions | 12.99IN L x 8.66IN W x 8.27IN H |
| UPC/EAN | 6940561905342 |
| Sold As | 1 Each |
Choosing between options
- Flat or square parts: 6521-80 universal vise without the chuck.
Request a Quote
Need volume pricing or help matching the right Insize part?
Send the part number, quantity and part diameter and the angles you need to set — we reply the same day.
Contact Information
Authorized Insize distributor
📍 Nationwide shipping | Live Oak, TX
Additional Information
Brand: |
Insize |
Manufacturer Part Number: |
6528-85 |
Product Family: |
Testing and Specialty Instruments |
Supplier Category Code: |
A |
EAN: |
6940561905342 |
Package Weight: |
24.25 lb |
Package Length: |
12.99 in |
Package Width: |
8.66 in |
Package Height: |
8.27 in |
Feature 1: |
Horizontal rotary: range 360°, grad 0.05°. |
Feature 2: |
Vertical incline: range 45°, graduation 0.05° |
Feature 3: |
With vertical incline adjust knob. |
Feature 4: |
Runout of chuck is less than .0003'(test position is at less than 1.97' from clamping jaws). |
Feature 5: |
The clamping jaws of chunk are reversible. |
Feature 6: |
Made of tool steel |
Feature 7: |
Hardness HRC56-58. |
