Insize 4860-15 – Gear Tooth Pitch Gage, 14.5° Pressure Angle, Range 2-5, Pressure angle14.5°
L. Dewitt's SKU #: 4860-15 | Mfr Part #: 4860-15Insize 4860-15 is a gear tooth pitch gage for identifying the diametral pitch of gears from 2-5 DP with a 14.5° pressure angle, in hardened stainless steel.
Key Features
- Diametral pitch range 2-5
- Pressure angle 14.5°
- Accuracy ±.002IN
- Hardened stainless steel
Technical Specifications
| Part Number | 4860-15 |
| Brand | Insize |
| Manufacturer Part Number | 4860-15 |
| Product Type | Gear Tooth Pitch Gage, 14.5° Pressure Angle |
| Diametral Pitch Range | 2-5 |
| Pressure Angle | 14.5° |
| Accuracy | ±.002IN |
| Material | Hardened stainless steel |
| Availability | Ships direct from Insize; most items in stock. Ship date confirmed by email after you order. |
| Shipping Weight | 0.28 lb |
| Package Dimensions | 4.33IN L x 3.82IN W x 0.08IN H |
| UPC/EAN | 6928640386763 |
| Sold As | 1 Each |
Choosing between options
- 14.5° vs 20°: 4860-25 covers the same 2-5 pitch range for 20° pressure angle gears.
Other sizes & versions in this series
Request a Quote
Need volume pricing or help matching the right Insize part?
Send the part number, quantity and pitch range and pressure angle — we reply the same day.
Contact Information
Authorized Insize distributor
📍 Nationwide shipping | Live Oak, TX
Additional Information
Brand: |
Insize |
Manufacturer Part Number: |
4860-15 |
Product Family: |
Gages and Reference Tools |
Supplier Category Code: |
A |
EAN: |
6928640386763 |
Package Weight: |
0.28 lb |
Package Length: |
4.33 in |
Package Width: |
3.82 in |
Package Height: |
0.08 in |
Feature 1: |
Check the diameterical pitch of gear tooth. |
Feature 2: |
Accuracy: ±.002'. |
Feature 3: |
Made of hardened stainless steel |
