Insize 4824-16 – Pitch Gage, Inch (TPI), 1-12TPI
L. Dewitt's SKU #: 4824-16 | Mfr Part #: 4824-16Insize 4824-16 is a 16-leaf screw pitch gage for coarse inch pitches from 1-12 TPI, for identifying and checking large screw threads.
Key Features
- 16 leaves, 1-12 TPI
- Accuracy ±.0028IN
- Medium carbon steel
Technical Specifications
| Part Number | 4824-16 |
| Brand | Insize |
| Manufacturer Part Number | 4824-16 |
| Product Type | Pitch Gage, Inch (TPI) |
| Range | 1-12 TPI |
| Leaves | 16 |
| Accuracy | ±.0028IN |
| Material | Medium carbon steel |
| Availability | Ships direct from Insize; most items in stock. Ship date confirmed by email after you order. |
| Shipping Weight | 0.47 lb |
| Package Dimensions | 4.72IN L x 1.97IN W x 1.38IN H |
| UPC/EAN | 6928640319198 |
| Sold As | 1 Each |
Choosing between options
- Finer inch pitches: 4820-230 covers 4-42 TPI.
Other sizes & versions in this series
- 4824-12 – 2-20MM
Request a Quote
Need volume pricing or help matching the right Insize part?
Send the part number, quantity and thread pitch range (TPI or metric) — we reply the same day.
Contact Information
Authorized Insize distributor
📍 Nationwide shipping | Live Oak, TX
Additional Information
Brand: |
Insize |
Manufacturer Part Number: |
4824-16 |
Product Family: |
Gages and Reference Tools |
Supplier Category Code: |
A |
EAN: |
6928640319198 |
Package Weight: |
0.47 lb |
Package Length: |
4.72 in |
Package Width: |
1.97 in |
Package Height: |
1.38 in |
Feature 1: |
Check the pitch of screw thread. |
Feature 2: |
Accuracy: ±.0028'. |
Feature 3: |
Quantity of leaves: 16 |
Feature 4: |
Made of medium carbon steel |
