Insize 4635-1B19N – Whitworth Pipe Thread Ring Gage (G Series), No Go, G 1/4-19
L. Dewitt's SKU #: 4635-1B19N | Mfr Part #: 4635-1B19NInsize 4635-1B19N is the NO GO ring gage for G 1/4-19 Whitworth parallel pipe threads (G series), class A to ISO 228. It confirms an external thread is not oversize; pair it with the matching GO ring gage.
Please note: This is the NO GO ring only. GO and NO GO gages are sold separately.
Key Features
- Thread size G 1/4-19 (G series, parallel)
- Class A
- Made to ISO 228
- NO GO member only; GO gage sold separately
Technical Specifications
| Part Number | 4635-1B19N |
| Brand | Insize |
| Manufacturer Part Number | 4635-1B19N |
| Product Type | Whitworth Pipe Thread Ring Gage (G Series), No Go |
| Thread Size | G 1/4-19 |
| Thread Form | Whitworth parallel pipe (G series) |
| Class | A |
| Standard | ISO 228 |
| Gage Member | NO GO |
| Availability | Ships direct from Insize; most items in stock. Ship date confirmed by email after you order. |
| Shipping Weight | 0.15 lb |
| Package Dimensions | 2.2IN L x 2.05IN W x 0.87IN H |
| UPC/EAN | 6928640375439 |
| Sold As | 1 Each |
What you'll also need
- Matching GO ring gage 4635-1B19 (sold separately)
Choosing between options
Other sizes & versions in this series
- 4635-1A14 – G 1/2-14, Go
- 4635-1A14N – G 1/2-14, Nogo
- 4635-1B19 – G 1/4-19, Go
- 4635-1C28 – G 1/8-28, Go
- 4635-1C28N – G 1/8-28, Nogo
- 4635-1G11 – G 1.1/4-11, Go
- 4635-1G11N – G 1.1/4-11, Nogo
- 4635-1H11 – G 1.1/2-11, Go
