Insize 4131-7D2 – American Standard Thread Plug Gage, Go and No Go, 7/16-20UNF
L. Dewitt's SKU #: 4131-7D2 | Mfr Part #: 4131-7D2Insize 4131-7D2 is a thread plug gage for 7/16-20UNF internal threads, class 2B to ANSI/ASME B1.2, with GO and NO GO members supplied together. The GO member must thread in fully; the NO GO member checks that the pitch diameter is not oversize.
Key Features
- Thread size 7/16-20UNF, tolerance class 2B
- Made to ANSI/ASME B1.2
- GO and NO GO members supplied together
- Manufacturer inspection certificate included
Technical Specifications
| Part Number | 4131-7D2 |
| Brand | Insize |
| Manufacturer Part Number | 4131-7D2 |
| Product Type | American Standard Thread Plug Gage, Go and No Go |
| Thread Size | 7/16-20UNF |
| Tolerance Class | 2B |
| Gage Members | GO and NO GO |
| Standard | ANSI/ASME B1.2 |
| Certificate | Manufacturer inspection certificate |
| Availability | Ships direct from Insize; most items in stock. Ship date confirmed by email after you order. |
| Shipping Weight | 0.11 lb |
| Package Dimensions | 3.94IN L x 0.94IN W x 0.94IN H |
| UPC/EAN | 6928640359002 |
| Sold As | 1 Each |
Choosing between options
Other sizes & versions in this series
Request a Quote
Need volume pricing or help matching the right Insize part?
Send the part number, quantity and thread size, pitch and class — we reply the same day.
Contact Information
Authorized Insize distributor
📍 Nationwide shipping | Live Oak, TX
Additional Information
Brand: |
Insize |
Manufacturer Part Number: |
4131-7D2 |
Product Family: |
Gages and Reference Tools |
Supplier Category Code: |
A |
EAN: |
6928640359002 |
Package Weight: |
0.11 lb |
Package Length: |
3.94 in |
Package Width: |
0.94 in |
Package Height: |
0.94 in |
Feature 1: |
Class 2B. |
Feature 2: |
Standard ANSI/ASME B1.2 |
Feature 3: |
Supplied with Go and No-Go gages together |
Feature 4: |
Supplied with manufacturer inspection certificate. |
