Insize 4120-5N – Metric Thread Ring Gage, No Go, M5x0.8
L. Dewitt's SKU #: 4120-5N | Mfr Part #: 4120-5NInsize 4120-5N is the NO GO ring gage for M5x0.8 external threads, class 6g to ISO 1502. It checks that the pitch diameter is not below the minimum limit: a good thread should not screw into it. Pair it with the matching GO ring gage.
Please note: This is the NO GO ring only. GO and NO GO gages are sold separately.
Key Features
- Thread size M5x0.8, tolerance class 6g
- Made to ISO 1502
- NO GO member only; GO gage sold separately
- Manufacturer inspection certificate included
Technical Specifications
| Part Number | 4120-5N |
| Brand | Insize |
| Manufacturer Part Number | 4120-5N |
| Product Type | Metric Thread Ring Gage, No Go |
| Thread Size | M5x0.8 |
| Tolerance Class | 6g |
| Gage Member | NO GO |
| Standard | ISO 1502 |
| Certificate | Manufacturer inspection certificate |
| Availability | Ships direct from Insize; most items in stock. Ship date confirmed by email after you order. |
| Shipping Weight | 0.04 lb |
| Package Dimensions | 1.57IN L x 1.57IN W x 0.59IN H |
| UPC/EAN | 6928640341717 |
| Sold As | 1 Each |
What you'll also need
- Matching GO ring gage 4120-5 (sold separately)
