Description
Insize 4120-36N – Metric Thread Ring Gage, No Go, M36x4
L. Dewitt's SKU #: 4120-36N | Mfr Part #: 4120-36NInsize 4120-36N is the NO GO ring gage for M36x4 external threads, class 6g to ISO 1502. It checks that the thread's pitch diameter is not below the minimum; pair it with the matching GO ring gage, which checks that the thread is not oversize.
Please note: This is the NO GO ring only. GO and NO GO gages are sold separately.
Key Features
- Thread size M36x4, tolerance class 6g
- Made to ISO 1502
- NO GO member only; GO gage sold separately
- Manufacturer inspection certificate included
Technical Specifications
| Part Number | 4120-36N |
| Brand | Insize |
| Manufacturer Part Number | 4120-36N |
| Product Type | Metric Thread Ring Gage, No Go |
| Thread Size | M36x4 |
| Tolerance Class | 6g |
| Gage Member | NO GO |
| Standard | ISO 1502 |
| Certificate | Manufacturer inspection certificate |
| Availability | Ships direct from Insize; most items in stock. Ship date confirmed by email after you order. |
| Shipping Weight | 1.34 lb |
| Package Dimensions | 4.02IN L x 3.78IN W x 1.73IN H |
| UPC/EAN | 6928640341885 |
| Sold As | 1 Each |
What you'll also need
- Matching GO ring gage (sold separately)
Choosing between options
- The matching GO ring is 4120-36 (M36x4, class 6g). Order both to fully check a thread: GO must thread on, NO GO must not.
Other sizes & versions in this series
Request a Quote
Need volume pricing or help matching the right Insize part?
Send the part number, quantity and thread size, pitch, class and GO / NO GO — we reply the same day.
Contact Information
Authorized Insize distributor
📍 Nationwide shipping | Live Oak, TX
Additional Information
Brand: |
Insize |
Manufacturer Part Number: |
4120-36N |
Product Family: |
Gages and Reference Tools |
Supplier Category Code: |
A |
EAN: |
6928640341885 |
Package Weight: |
1.34 lb |
Package Length: |
4.02 in |
Package Width: |
3.78 in |
Package Height: |
1.73 in |
Feature 1: |
Go and No-Go gages are supplied separately. |
Feature 2: |
Class 6g. |
Feature 3: |
Standard ISO1502. |
Feature 4: |
Supplied with manufacturer inspection certificate. |
