Insize 4120-2D2N – Metric Thread Ring Gage, No Go, M2.2x0.45

(No reviews yet) Write a Review

Tracked & insured shipping

Free Returns



30 Days Money Back Guarantee

SKU:
4120-2D2N
UPC:
6928640341663
MPN:
4120-2D2N
Availability:
Ships direct from Insize. Most items in stock; we confirm your ship date by email after you order.
Weight:
0.03 LBS
Width:
1.57 (in)
Height:
0.59 (in)
Depth:
1.65 (in)
Shipping:
Calculated at Checkout
$79.70

Sold Out

Frequently bought together:

Description

Insize 4120-2D2N – Metric Thread Ring Gage, No Go, M2.2x0.45

L. Dewitt's SKU #: 4120-2D2N  |  Mfr Part #: 4120-2D2N

Insize 4120-2D2N is the NO GO ring gage for M2.2x0.45 external threads, class 6g to ISO 1502. It checks that the pitch diameter is not below the minimum limit: a good thread should not screw into it. Pair it with the matching GO ring gage.

Please note: This is the NO GO ring only. GO and NO GO gages are sold separately.

Key Features

  • Thread size M2.2x0.45, tolerance class 6g
  • Made to ISO 1502
  • NO GO member only; GO gage sold separately
  • Manufacturer inspection certificate included

Technical Specifications

Part Number4120-2D2N
BrandInsize
Manufacturer Part Number4120-2D2N
Product TypeMetric Thread Ring Gage, No Go
Thread SizeM2.2x0.45
Tolerance Class6g
Gage MemberNO GO
StandardISO 1502
CertificateManufacturer inspection certificate
AvailabilityShips direct from Insize; most items in stock. Ship date confirmed by email after you order.
Shipping Weight0.03 lb
Package Dimensions1.65IN L x 1.57IN W x 0.59IN H
UPC/EAN6928640341663
Sold As1 Each

What you'll also need

  • Matching GO ring gage 4120-2D2 (sold separately)

Choosing between options

  • The matching GO ring is 4120-2D2 (M2.2x0.45, class 6g). Order both to fully check a thread: GO must thread on, NO GO must not.
  • Checking internal threads instead? 4130-2D2 is the M2.2x0.45 thread plug gage (class 6H), GO and NO GO supplied together.

Other sizes & versions in this series

See all 62 products in the Insize 4120 series

Request a Quote

Need volume pricing or help matching the right Insize part?

Send the part number, quantity and thread size, pitch, class and GO / NO GO — we reply the same day.
