Insize 4002-B27 – Angle Gage Block, 27'
L. Dewitt's SKU #: 4002-B27 | Mfr Part #: 4002-B27Insize 4002-B27 is a single 27 arc-minute angle gage block, accurate to ±2 arc-seconds. Use it to inspect protractors, taper gages, index plates and index heads, to set an angle, or to add to or complete an angle block set.
Build your kit – save 5%
Add a matching accessory to this tool in the same order and 5% comes off both automatically in your cart.
| Gage block holders and jaws | 6881-A1, 6881-A2 holders and 6881-E1E jaws turn a stack into a snap gage. We confirm fit for your set. | Choose yours |
Send us this part number and what you measure — we match the accessories you need and quote the kit the same day.Match my kit
Kit savings need at least one tool and one accessory in the same order. Excludes QMS, LDM, TLP and UTM measuring machines.
Key Features
- Angle 27' (27 arc-minutes)
- Accuracy ±2 arc-seconds
- For inspecting protractors, taper gages, index plates, index heads and goniometers; also used to set angles
- Special alloy steel, hardness HRC64; wear resistant and easy to combine
Technical Specifications
| Part Number | 4002-B27 |
| Brand | Insize |
| Manufacturer Part Number | 4002-B27 |
| Product Type | Angle Gage Block |
| Angle | 27' (27 arc-minutes) |
| Accuracy | ±2 arc-seconds |
| Material | Special alloy steel |
| Hardness | HRC64 |
| Availability | Ships direct from Insize; most items in stock. Ship date confirmed by email after you order. |
| Shipping Weight | 0.59 lb |
| Package Dimensions | 6.1IN L x 4.72IN W x 1.18IN H |
| UPC/EAN | 6928640354298 |
| Sold As | 1 Each |
Choosing between options
Other sizes & versions in this series
Request a Quote
Need volume pricing or help matching the right Insize part?
Send the part number, quantity and the angle(s) you need — we reply the same day.
Contact Information
Authorized Insize distributor
📍 Nationwide shipping | Live Oak, TX
Additional Information
Brand: |
Insize |
Manufacturer Part Number: |
4002-B27 |
Product Family: |
Gages and Reference Tools |
Supplier Category Code: |
A |
EAN: |
6928640354298 |
Package Weight: |
0.59 lb |
Package Length: |
6.1 in |
Package Width: |
4.72 in |
Package Height: |
1.18 in |
Feature 1: |
Accuracy: ±2'. |
Feature 2: |
To inspect protractor, taper gage, index plate, index head and goniometer, can also be used to set angle. |
Feature 3: |
Made of special alloy steel, hardness HRC64, high stability, wear resistance and easy combination. |
Feature 4: |
Can be combined to any angle with interval 6 seconds after combination (6', 12', 18', ... , 360°). |
