Description
Insize 2307-0255 – Dial Indicator, Lug Back, .25IN
L. Dewitt's SKU #: 2307-0255 | Mfr Part #: 2307-0255Insize 2307-0255 is a .25IN range dial indicator with .0005IN graduation and a lug back for mounting on stands, fixtures and gages. Made to ASME B89.1.10M-2001.
Build your kit – save 5%
Add a matching accessory to this tool in the same order and 5% comes off both automatically in your cart.
| Magnetic stand 6201-60 | Holds the indicator on any steel surface for setup and runout checks. | Add to cart |
| Magnetic stand, larger 6202-80 | Longer reach and fine adjustment for bigger setups. | Add to cart |
Send us this part number and what you measure — we match the accessories you need and quote the kit the same day.Match my kit
Kit savings need at least one tool and one accessory in the same order. Excludes QMS, LDM, TLP and UTM measuring machines.
Key Features
- Range .25IN, graduation .0005IN
- Lug back
- Limit pointers and bezel clamp included
- Meets ASME B89.1.10M-2001
Technical Specifications
| Part Number | 2307-0255 |
| Brand | Insize |
| Manufacturer Part Number | 2307-0255 |
| Product Type | Dial Indicator, Lug Back |
| Range | .25IN |
| Graduation | .0005IN |
| Back | Lug back |
| Standard | ASME B89.1.10M-2001 |
| Availability | Ships direct from Insize; most items in stock. Ship date confirmed by email after you order. |
| Shipping Weight | 0.8 lb |
| Package Dimensions | 6.1IN L x 3.82IN W x 2.64IN H |
| UPC/EAN | 6928640329470 |
| Sold As | 1 Each |
What you'll also need
- Optional backs and contact points
Choosing between options
- ISO 17025 calibration certificate available on request through Insize; cost and lead time quoted.
- Coarser graduation, same .25IN range: 2307-025 reads .001IN.
Other sizes & versions in this series
Request a Quote
Need volume pricing or help matching the right Insize part?
Send the part number, quantity and range, graduation and back style and whether you need an ISO 17025 calibration certificate — we reply the same day.
Contact Information
Authorized Insize distributor
📍 Nationwide shipping | Live Oak, TX
Additional Information
Brand: |
Insize |
Manufacturer Part Number: |
2307-0255 |
Product Family: |
Indicators and Test Indicators |
Supplier Category Code: |
A |
EAN: |
6928640329470 |
Package Weight: |
0.8 lb |
Package Length: |
6.1 in |
Package Width: |
3.82 in |
Package Height: |
2.64 in |
Feature 1: |
Graduation .0005' |
Feature 2: |
Meet ASME B89.1.10M-2001. |
Feature 3: |
Supplied with limit pointers and bezel clamp. |
Feature 4: |
Optional accessory: backs, contact points. |
