Description
Insize 2187-19 – Adjustable Snap Gage, .51-.75IN
L. Dewitt's SKU #: 2187-19 | Mfr Part #: 2187-19Insize 2187-19 is an adjustable snap gage for .51-.75IN diameters. Set the GO and NO GO anvils to your upper and lower limits with gage blocks or a master, then check shafts and pins without reading a scale.
Key Features
- Range .51-.75IN
- Set upper and lower limits to use as a GO/NO GO gage
- Anvil flatness 59μin
- Parallelism between tips and anvil 118μin (ranges up to 1.26IN)
Technical Specifications
| Part Number | 2187-19 |
| Brand | Insize |
| Manufacturer Part Number | 2187-19 |
| Product Type | Adjustable Snap Gage |
| Range | .51-.75IN |
| Anvil Flatness | 59μin |
| Parallelism | 118μin |
| Availability | Ships direct from Insize; most items in stock. Ship date confirmed by email after you order. |
| Shipping Weight | 1.17 lb |
| Package Dimensions | 7.87IN L x 4.72IN W x 1.77IN H |
| UPC/EAN | 6928640314384 |
| Sold As | 1 Each |
What you'll also need
- Gage blocks or a master part to set the limits
Choosing between options
- Need to read the actual size? 2186-25E is a 0-1IN dial snap gage frame (indicator sold separately).
Other sizes & versions in this series
Request a Quote
Need volume pricing or help matching the right Insize part?
Send the part number, quantity and the part diameter and your upper and lower limits — we reply the same day.
Contact Information
Authorized Insize distributor
📍 Nationwide shipping | Live Oak, TX
Additional Information
Brand: |
Insize |
Manufacturer Part Number: |
2187-19 |
Product Family: |
Gages and Reference Tools |
Supplier Category Code: |
A |
EAN: |
6928640314384 |
Package Weight: |
1.17 lb |
Package Length: |
7.87 in |
Package Width: |
4.72 in |
Package Height: |
1.77 in |
Feature 1: |
Used as Go/No-Go gage by setting upper and lower limits. |
Feature 2: |
Flatness of anvil: 59μin. |
Feature 3: |
Parallelism between tips and anvil: range 0-1.26': 118μin, |
