Insize 1103-300 – Digital Caliper (Absolute System), 0-12IN/0-300MM
L. Dewitt's SKU #: 1103-300 | Mfr Part #: 1103-300Insize 1103-300 is a 0-12IN/0-300MM absolute-system digital caliper reading to .0005IN/0.01MM. The absolute system keeps the origin when the caliper is switched off, so you set it once instead of re-zeroing at each power-up, and low power draw gives long battery life.
Key Features
- Range 0-12IN/0-300MM, resolution .0005IN/0.01MM
- Absolute system: origin is kept at power-off (ORIGIN button to set)
- Low power consumption, long battery life
- Buttons: on/off, inch/mm, ORIGIN, ZERO/ABS
- Auto power off; moving the slider turns it back on
- CR2032 battery; data output
- Stainless steel construction
Technical Specifications
| Part Number | 1103-300 |
| Brand | Insize |
| Manufacturer Part Number | 1103-300 |
| Product Type | Digital Caliper (Absolute System) |
| Range | 0-12IN / 0-300MM |
| Resolution | .0005IN / 0.01MM |
| Data Output | Yes (cable sold separately) |
| Battery | CR2032 |
| Material | Stainless steel |
| Availability | Ships direct from Insize; most items in stock. Ship date confirmed by email after you order. |
| Shipping Weight | 1.73 lb |
| Package Dimensions | 16.89IN L x 5.16IN W x 1.3IN H |
| UPC/EAN | 6928640300356 |
| Sold As | 1 Each |
What you'll also need
- Wireless transmitter (sold separately) to send readings without a cable
- Data output cable (sold separately) to connect to a computer
Choosing between options
- Don't need the absolute system? 1108-300 is the standard-type 0-12IN/0-300MM digital caliper with data output.
