Description
DEWALT DW735 13 in. (330mm) Three Knife, Two Speed Thickness Planer (15 Amp)
L. Dewitt's SKU #: DW735 | Mfr Part #: DW735
Overview
Benchtop thickness planer powered by a 15 Amp, 120V motor to easily manage large cuts in wider materials. A three-knife cutter head running at 10,000 RPM with feed speed options for 96 or 179 CPI provides optimal cut performance, and fan-assisted chip ejection vacuums chips off the cutter head and exhausts them from the machine.
Features
- Powerful 15 Amp, 20,000 RPM motor handles larger cuts in wider materials
- Three-knife cutter head delivers 30% longer knife life and makes knife changes faster and easier
- Two-speed gearbox allows users to change feed speed to optimize cuts per inch at 96 or 179 CPI
- Fan-assisted chip ejection vacuums chips off the cutter head and exhausts them out of the machine
- Cast aluminum base is 2x more rigid than a standard 10 in. base
- Automatic carriage lock reduces the movement that causes snipe without manual engagement
- Material removal gauge and extra-large thickness scale for accurate cuts
- Extra-large turret depth stop for frequently used thicknesses
- UL listed
What's in the Box
- Dust hose adapter
- Thickness planer crank handle
- Blade change T-wrench
Specifications
| Voltage | 120V |
| Amperage | 15 Amps |
| Planing Width | 13 in. (330mm) |
| Motor Speed | 20,000 RPM |
| Cutter Head Speed | 10,000 RPM |
| Cutter Head | 3-knife |
| Feed Speeds | 96 or 179 CPI (two-speed gearbox) |
| Feed Rate | 14 ft/min (speed 1), 26 ft/min (speed 2) |
| Max Depth Capacity | 6 in. |
| Max Depth of Cut | 1/8 in. |
| Base | 19-3/4 in. cast aluminum |
| Tool Weight | 92 lbs |
Warranty: 3 Year Limited Warranty, 1 Year Free Service, 90 Days Satisfaction Guaranteed
Request a Quote
Need volume pricing, availability, or help finding the right part?
Send us your part numbers and quantities — our technical team responds fast during business hours.
Contact Information
Industrial supply distributor
📍 Nationwide shipping | Live Oak, TX
Additional Information
Brand: |
DEWALT |
Manufacturer Part Number: |
DW735 |
Supplier Part Number: |
115-DW735 |
Vendor Name: |
Stanley-Proto * |
Product Category: |
Power Tools |
Product Subcategory: |
Finishing Tools |
Unit of Sale: |
Ea |
Minimum Order Quantity: |
1 |
UOM Conversion: |
1 EA = 1 EA |
Cost UOM: |
Ea |
Price Basis: |
Standard package |
Country of Origin: |
Taiwan; Republic of China |
Hazmat Item: |
No |
Special Order Item: |
No |
State Restricted: |
No |
